74LS628 VOLTAGE-CONTROLLED OSCILLATORS
General Description
These voltage-controlled oscillators (VCOs) are improved versions of the original VCO family: SN54LS124. SN54LS324 thru SN54LS327, SN74LS 124, and SN74LS324 thru SN74LS327. These new devices feature improved voltage-to frequency linearity, range, and compensation. With the exception of the ‘LS624 and ‘LS628, all of these devices feature two independent VCOs in a single monolithic chip. The ‘LS624, ‘LS625, ‘LS626, and ‘LS628 have complementary Z outputs. The output frequency for each VCO is established by a single external component (either a capacitor or crystal in combination with voltage-sensitive inputs used for frequency control and frequency range. Each device has a voltage-sensitive input for frequency control; however, the ‘LS624, ‘LS628, and ‘LS629 devices also have one for frequency range.
